EnerSure® Enkapsis

The EnerSure® Enkapsis sets a new standard for Power Quality Meters (PQM) as both a standalone three-phase PQM and the foundation for the entire suite of EnerSure® devices (EnerSure® BCPM 2.0, EnerSure® iBCPM, and EnerSure® Bus). These products are used to provide utility grade data at the branch circuit on busway systems, panelboards, RPPs, PDUs, switchgear, and distribution panels.

The EnerSure® Enkapsis delivers highly accurate measurements of all power metrics. Its functionality extends beyond the harmonic data provided by traditional PQMs with support for the triggering and retrieval of voltage and current waveforms.

>>>Download EnerSure® Enkapsis Datasheet<<<


The EnerSure® Enkapsis is the backbone for the EnerSure® platform featuring:


Total Harmonic Distortion (THD) Metrics
The EnerSure® Enkapsis captures individual current & voltage harmonics (up to the 45th harmonic) to keep sensitive equipment from being damaged by power harmonics over time.


Waveform Capture
Waveform capture capabilities provide a visualization of power consumption and power quality events that take place in the critical facility.


Onboard Ethernet
The EnerSure® Enkapsis platform provides all standard forms of data connectivity without the need for gateways or additional hardware. The open protocols allow all EnerSure® products to be easily integrated into any data center or building management system.


Data and Event Logging
The 9 onboard data logs on the EnerSure® Enkapsis can record up to 120 data points each in 30 second intervals. Using a standard on-board microSD card, users can record thousands of time-stamped data points. The data logs can then be downloaded as a .CSV file or delivered using Modbus TCP or BACnetIP protocols.


The EnerSure® Enkapsis allows you to manage your circuit capabilities with greater reliability, having the best total system accuracy on the market. Our meters achieve 1% accuracy.


Current Transformer
Our split core CTs allow users to vary their CTs used throughout their system. CTs can be added or removed after the system is deployed and are available in any size from our standard 75 to 300 amp series up to 10,000 amps. TrendPoint CTs do not require shorting blocks as they are internally burdened.


Environmental Monitoring
Detect abnormal temperature and humidity conditions with the on-board environmental communications port which uses Dallas 1-wire environmental sensors.
